INTRODUCTION
Thanks and congratulations for choosing STEG for your audio amplification and digital
signal processing needs. These amplifiers have been significantly improved
throughout the years in order to assure quality and reliability. The latest technology
has been incorporated into every product, providing you with incredible power and
unparalleled sound quality. Our highly developed and simplified circuitry contributes
to low distortion and the ultimate in efficiency. That's why we are sure that your new
DSP amplifier will provide you with a sound value you can enjoy for years to come.
2
Note: All specifications are subject to change without notice.
8.3” (210mm)
9.8" (249mm)
8.3" (210mm)
2.3" (58mm)
11.1" (283mm)
2.3" (58mm)
SDSP6 SDSP8
SDSP6 SDSP8
4Ω, 14.4V, <1% THD+N 60W x 6 60W x 8
2Ω, 14.4V, <1% THD+N 90W x 6 90W x 8
+0/-3dB, 1W, 4Ω 20Hz - 22kHz 20Hz - 22kHz
Spk Out at 1W / rated pwr, 4Ω >74dBA / >92dBA >74dBA / >92dBA
RCA Out at 2V / 5V >92dBA / >100dBA >92dBA / >100dBA
½ Rated Pwr, 4Ω <0.07% <0.07%
High Level
High Level 2.5-10V 2.5-10V
AUX 0.3-2.5V 0.3-2.5V
Max Output voltage >5Vrms >5Vrms
Output Impedance 450Ω 450Ω
via REM IN >3.3VDC >3.3VDC
DC-Offset >3.2VDC >3.2VDC
Current Capacity >100mA >100mA
End Panel, ATC 30A x 1 25A x 2
Idle Current 1.2A 1.5A
Sleep Current 1.6mA 1.8mA
DC Supply 8-16V, <5sec at 6V 8-16V, <5sec at 6V
9.8"x8.3"x2.3" 11.1"x8.3"x2.3"
249x210x58mm 283x210x58mm
