WCM CTX8010 - Page 6

6
Overall dimensions
Unit: mm
A Wheel track
962
B Overall length of track
1282
C Ground clearance of platform
377.5
D Ground clearance of platform tail
843.5
E Chassis width
960
F Crawler width
161.12
H Crawler height
330.53
I Transportation length
2796.48
J Overall height
1155
Work range
Unit: mm
A Max. digging radius on ground
3017.16
B Max. digging depth
1745.55
C Max. digging height
2842
D Max. unloading height
1919.82
E Max. vertical digging depth
1371.51
F Min. swing radius
1292.67
G Max. lifting height of dozer blade
347
H Max. digging depth of dozer blade
255
Performance parameters
Weight of complete machine kg
1000
Standard bucket capacity m³
0.025
Rated power kw
7.5
