WD Black D50 - WD_BLACK D50 Game Dock Connectors; Port Overview and Indicators

Gigabit Ethernet Port - This Ethernet
port supports 1000BASE-T as defined in
the IEEE 802.3ab standard.
Thunderbolt 3 - The port labeled 87W to PC supports the
following protocols: Thunderbolt 3, DisplayPort 1.4, and
Superspeed USB 10Gbps. With the use of a Thunderbolt 3
cable, this port can supply up to 87-watts of power to a host
computer.
Thunderbolt 3 - This port supports the following protocols:
Thunderbolt 3, DisplayPort 1.4, and SuperSpeed USB
10Gbps. This port provides up to 15-watts of power.
DisplayPort
TM
- This DisplayPort receptacle supports the standard 20-pin DisplayPort connector and
specifications for version 1.4
3
.
USB Type-C
TM
- This port supports SuperSpeed USB 10Gbps
and up to 15-watts maximum power.
Power Connector - for included
180-watt (19.5VDC/ 9.23ADC) power
supply.
USB Type-A - These ports support SuperSpeed USB 10Gbps
and up to 7.5-watts maximum power.
WD_BLACK D50 GAME DOCK / WD_BLACK D50 GAME DOCK WITH NVMe SSD STORAGE
CONNECTORS
USB Type-C
TM
- This port supports SuperSpeed USB 10Gbps
and up to 15-watts maximum power.
USB Type-A - This port supports SuperSpeed USB 10Gbps and up
to 7.5-watts maximum power. This is also a dedicated charging
port that will continue to charge your device even when the dock
is not connected to a host or is in a low-power state.
Audio IN/OUT - This 3.5mm audio jack connects to a
headset with built-in microphone.
Front LED - This LED provides device status.
- 2 -
RGB LED - The settings for the RGB LED lights can be
controlled via the WD_BLACK Dashboard software
(Windows® only).
Intelligent Fan - For active cooling.
