PARTS DIAGRAM - WEBV26 MACHINE (193867003)
PARTS LIST - WEBV26 MACHINE (193867003)
Item
Part No.
Description
Qty
Item
Part No.
Description
Qty
1
WE70050010068
Tube A
1
30
WE70030160048
Upper Handle
1
2
WE70050010069
Tube B
1
31
WE03010040068
Screw ST4.2x12
1
3
WE03010040048
Screw M5x16
11
32
WE03010040025
Screw ST4.2x13
1
4
WE03020020028
Screw M5x16
3
33
WE02050050141
Stop Wire
1
5
WE70030030284
Connect Cover
1
34
WE51010040002
Engine
1
6
WE03010060078
Screw M5x10
3
35
WE03110020023
Seal 2.5x2
1
7
WE70030180100
Safety Cover
1
36
WE70030031189
Recoil Casing
1
8
WE02050050002
Safety Switch
1
37
WE70030160229
Throttle Lock
1
9 WE70030070032
Button
Connector
1 38 WE03040050074 Washer 1
10 WE03040050017 Washer 6 1 39 WE70030160230
Throttle Lock
Joint
1
11
WE70030180015
Screw
1
40
WE03020020018
Screw M5x10
3
12
WE70030031188
Fan Cover
1
41
WE03020020041
Screw M5x30
5
13
WE02020160312
Spring Shaft
1
42
WE70050010070
Curved Tube
1
14
WE02020110048
Spring
1
43
WE02050040087
Throttle Wire
1
15
WE70030010071
Rear Case
1
44
WE02050060050
Collection Bag
1
16
WE03030020002
Nut M8x1
1
45
WE02050060022
Harness
1
17 WE02020070042 Shatter Tooth 1 46 WE02120010045
Fuel Return Pipe
(L=70)
1
18 WE70030090019 Impellor 1 47 WE02080030025
Fuel Pipe
Rubber Bung
1
19 WE03010010069 Screw M5x30 4 48 WE02120010044
Fuel Inlet Pipe
(L=220)
1
20 WE02080020046
Left Hand
Rubber Cover
2 49 WE02050120002 Fuel Filter 1
21 WE70030010550 Body 1 50 WE02110020026
Fuel Cap
Assembly
1
22
WE02020160117
Pedestal
4
51
WE03050010007
Washer 8
1
23
WE70050030063
Fuel Tank
1
52
WE03040050005
Washer 23*8*1
1
24
WE03010040057
Screw M5x20
2
53
WE70050010066
Tube C
1
25
WE70030160093
Lower Handle
1
54
WE70050010188
Tube D
1
26 WE02020160398
Throttle Lever
Shaft
1 55 WE02050070129 Recoil Assembly 1
27 WE70030070716
Throttle Lever
Handle
1 56 WE02040030020 Bush 1
28
WE02050050344
Stop Switch
1
57
WE02080030015
Wire Lead
1
29
WE02050050171
Short Stop Wire
2
