Webb WEECS40 - Page 22

PARTS DIAGRAM - WEECS40 1938261001
PARTS LIST - WEECS40 1938261001
Item
No
Part No
Description
Qty
Item
No
Part No
Description
Qty
1
TH1800-0-1
Blade Guard
1
31
TH1800-0-21
Brake Lever
1
2
HP-111
Chain
1
32
TH1800-0-02
Large Gear Wheel
1
3
TH1800-0-37
Bar
1
TH1800-0-02-1
Large Gear Wheel Insert
1
4
TH1800-0-17
Adjusting Plate
1
33
Bearing 628 2RS
1
5
Screw ST4.2x10
3
34
Lock Nut M8
1
6
TH1800-0-18
Adjusting Block
1
35
TH1800-MOTOR
Motor Assembly
1
7
TH1800-0-19
Sprocket Cover
1
36
TH1800-0-14
Leaf Spring
1
8
WE180-1800-0-20-2
Adjusting Knob
1
37
TH1800-0-42
Micro-Switch
2
9
C-ring
1
38
WE180-1800-0-12-2
Left Housing
1
10
TH1800-0-04
Locking Knob
1
39
TH1800-0-11
Chain Brake
1
TH1800-0-04-1
Locking Knob Insert
1
TH1800-0-41
Chain Brake Insert
1
11
Screw M5x6
1
40
TH1800-0-10
Front Handle
1
12
Split Washer
1
41
TH1800-0-9
Motor Cover End Cap
1
13
TH1800-0-39
Sprocket
1
42
TH1800-0-8
Motor Cover
1
14
TH1800-0-38
Sprocket Spring
1
43
TH2200-0-27A
BS Plug & Power Cord
1
15
Screw ST4.8x19
12
44
Cable Sleeve
1
16
WE180-1800-0-15-2
Right Housing
1
45
Cord Clamp
1
17
TH1800-0-16
Spike
1
46
Terminal
1
18
TH1800-0-2
Oil Seal
1
47
TH1800-0-26
Cable Assembly
1
19
Screw ST4.2x12 B
4
48
TH1800-0-25
Cable 2
1
20
Flat Washer
2
49
TH1800-0-24
Cable 1
1
21
TH1800-0-13
Start Plate
1
50
TH1800-0-46
Trigger Spring
1
22
Flat Washer
1
51
WE180-1800-0-23-2
Trigger
1
23
Brake Rod Spring
1
52
WE180-1800-0-22-2
Safety Button
1
24
TH1800-0-05
Brake Rod
1
53
TH1800-0-45
Safety Button Spring
1
TH1800-0-05-1
Brake Rod Insert
1
54
TH1800-OIL TUBE
Oil Tube
1
25
Screw ST4.2*15 B
20
55
TH1800- OIL PUMP
Oil Pump Assembly
1
26
TH1800-0-01
Gearbox Cover
1
56
Oil Tube C-Clip
2
Stop Pin
1
57
TH1800-0-32
Spring
1
TH1800-0-01-1
Hex Bolt M8x25
1
58
TH1800-0-31
Oil Tank
1
27
Bearing 6000Z 2RS
1
59
TH1800-0-30
Oil Cap Washer
1
28
TH1800-0-3
Output Shaft
1
60
TH1800-0-29
Oil Cap Check Valve
1
29
TH1800-0-4
Torsion Spring
1
61
TH1800-0-28
Oil Cap
1
30
TH1800-0-5
Big Gear Ring Gasket
1
INSTRUCTION MANUAL
