PARTS DIAGRAM - WEECS40 1938261001
PARTS LIST - WEECS40 1938261001
Part No Description Qty
Part No Description Qty
1 TH1800-0-1 Blade Guard 1
31 TH1800-0-21 Brake Lever 1
2 HP-111 Chain 1
32
TH1800-0-02 Large Gear Wheel 1
3 TH1800-0-37 Bar 1
TH1800-0-02-1 Large Gear Wheel Insert 1
4 TH1800-0-17 Adjusting Plate 1
33 Bearing 628 2RS 1
5 Screw ST4.2x10 3
34 Lock Nut M8 1
6 TH1800-0-18 Adjusting Block 1
35 TH1800-MOTOR Motor Assembly 1
7 TH1800-0-19 Sprocket Cover 1
36 TH1800-0-14 Leaf Spring 1
8 WE180-1800-0-20-2 Adjusting Knob 1
37 TH1800-0-42 Micro-Switch 2
9 C-ring 1
38 WE180-1800-0-12-2 Left Housing 1
10
TH1800-0-04 Locking Knob 1
39
TH1800-0-11 Chain Brake 1
TH1800-0-04-1 Locking Knob Insert 1
TH1800-0-41 Chain Brake Insert 1
11 Screw M5x6 1
40 TH1800-0-10 Front Handle 1
12 Split Washer 1
41 TH1800-0-9 Motor Cover End Cap 1
13 TH1800-0-39 Sprocket 1
42 TH1800-0-8 Motor Cover 1
14 TH1800-0-38 Sprocket Spring 1
43 TH2200-0-27A BS Plug & Power Cord 1
15 Screw ST4.8x19 12
44 Cable Sleeve 1
16 WE180-1800-0-15-2 Right Housing 1
45 Cord Clamp 1
17 TH1800-0-16 Spike 1
46 Terminal 1
18 TH1800-0-2 Oil Seal 1
47 TH1800-0-26 Cable Assembly 1
19 Screw ST4.2x12 B 4
48 TH1800-0-25 Cable 2 1
20 Flat Washer 2
49 TH1800-0-24 Cable 1 1
21 TH1800-0-13 Start Plate 1
50 TH1800-0-46 Trigger Spring 1
22 Flat Washer 1
51 WE180-1800-0-23-2 Trigger 1
23 Brake Rod Spring 1
52 WE180-1800-0-22-2 Safety Button 1
24
TH1800-0-05 Brake Rod 1
53 TH1800-0-45 Safety Button Spring 1
TH1800-0-05-1 Brake Rod Insert 1
54 TH1800-OIL TUBE Oil Tube 1
25 Screw ST4.2*15 B 20
55 TH1800- OIL PUMP Oil Pump Assembly 1
26
TH1800-0-01 Gearbox Cover 1
56 Oil Tube C-Clip 2
Stop Pin 1
57 TH1800-0-32 Spring 1
TH1800-0-01-1 Hex Bolt M8x25 1
58 TH1800-0-31 Oil Tank 1
27 Bearing 6000Z 2RS 1
59 TH1800-0-30 Oil Cap Washer 1
28 TH1800-0-3 Output Shaft 1
60 TH1800-0-29 Oil Cap Check Valve 1
29 TH1800-0-4 Torsion Spring 1
61 TH1800-0-28 Oil Cap 1
30 TH1800-0-5 Big Gear Ring Gasket 1
