MAINTENANCE, CLEANING & STORAGE
WARNING
Improper maintenance & storage of the machine may void your warranty. Keep the machine clean for better
and safer performance.
Turn off the motor and remove the electrical plug from the power source before performing any
maintenance. Never tilt, lift, or carry the machine while the motor is running.
MAINTENANCE
General Recommendations
1. Always observe safety rules when performing any maintenance.
2. The warranty on this machine does not cover items that have been subjected to operator abuse or
negligence. The operator must maintain the machine as instructed.
3. Changing of the motor speed will void warranty.
4. All adjustments should be checked at least once each season.
5. Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition. Regular
maintenance is essential for safety and performance.
6. Do not use the equipment with worn or damaged parts, this can be dangerous. Parts are to be replaced
and not repaired. Use genuine spare parts. Parts that are not of the same quality can damage the
equipment and create safety hazards.
7. Wear strong work gloves when removing and reassembling the blade.
8. Check the blade’s balance after sharpening.
9. Check the grass flap and grassbox collector frequently for wear and deterioration.
10. Whenever the machine is to be handled, transported or tilted you must:
✓ Wear strong working gloves;
✓ Grasp the machine at the points that offer a safe grip, taking account of the blades, the mower’s
weight and its distribution.
BLADE MAINTENANCE
The cutting blade will continue to rotate after the motor is switched off. Slicing is possible if care is not
taken. Wear appropriate hand coverage.
1. Remove the electric plug from the mains supply.
2. Clean the underside of the deck with a stiff brush, before any maintenance is undertaken to the blade.
ELECTRICAL CONNECTION
The electrical motor installed is connected and ready for operation. The connection complies with the
applicable VDE and DIN provisions. The customer‘s mains connection as well as the extension cable used
must also comply with these regulations.
Damaged electrical connection cable
The insulation on electrical connection cables is often damaged.
This may have the following causes:
• Passage points, where connection cables are passed through windows or doors.
• Kinks where the connection cable has been improperly fastened or routed.
• Places where the connection cables have been cut due to being driven over.
• Insulation damage due to being ripped out of the wall outlet.
• Cracks due to the insulation ageing.
Damaged electrical connection cables must not be used and are life-threatening due to the insulation damage.
Check the electrical connection cables for damage regularly. Make sure that the connection cable does not
hang on the power network during the inspection.
Electrical connection cables must comply with the applicable VDE and DIN provisions. Only use connection
cables with the marking „H05VV-F“.
The printing of the type designation on the connection cable is mandatory.
AC motor
The mains voltage must be 230 V~
Extension cables up to 25m long must have a cross-section of 2.5 mm
2
.
Connections and repairs of electrical equipment may only be carried out by an electrician.
Please provide the following information in the event of any enquiries:
• Type of current for the motor
• Machine data - type plate
• The product meets the requirements of EN 61000- 3-11 and is subject to special connection conditions.
This means that use of the product at any freely selectable connection point is not allowed.
• Given unfavourable conditions in the power supply the product can cause the voltage to fluctuate
temporarily.
• The product is intended solely for use at connection points that
a. do not exceed a maximum permitted supply impedance “Z”, or
b. have a continuous current-carrying capacity of the mains of at least 100 A per phase.
• As the user, you are required to ensure, in consultation with your electric power company if necessary,
that the connection point at which you wish to operate the product meets one of the two requirements,
a) or b), named above.
