PARTS DIAGRAM – WEER36 (1938123001)
PARTS LIST – WEER36 (1938123001)
Item
No.
Part No. Description Qty
Item
No.
Part No. Description Qty
1 WE125-4080063 Switch Box Assembly 1 36 WE125-103050259 Rear Axle 1
2 WE125-103080036 Top Handle 1 37 WE124-301070916 Grass Flap 1
3 WE125-301062831 Switch Box Small Cover 1 38 WE125-301070924 Rear Wheel 2
4 WE125-103990876 Operator Handle 1 39 WE125-104010258 Washer 7
5 WE125-301070717 Left Permanent Seat 1 40 WE125-104050024 Split Washer 4
6 WE125-301062827 Left Clamp 1 41 WE125-301070923 Rear Wheel Trim 2
7 WE125-104040082 M4*8 Bolt 3 42 WE125-301062852 Height Adjuster 1
8 WE125-301070716 Left Fix Cover 1 43 WE125-103990880 Adjusting Lever 1
9 WE125-104030136 St4.2X15Bt Screw 21 44 WE125-104030203 M4*8 Screw 2
10 WE125-301070806 Cable Clip 2 45 WE125-103020130 Collector Support 1
11 WE125-301070899 Fixed Wrench 4 46 WE125-301062851 Pin Shaft 2
12 WE125-103990795 Spring Pin 4 47 WE125-103990799 Connecting Rod 1
13 WE125-104040202 M8×73 Bolt 2 48 WE125-103990811 Splitpin 3
14 WE125-301070779 Wrench Support 2 49 WE124-103990797 Press Plate 6
15 WE125-301070780 Knob Washer 2 50 WE125-301070837 Axle Cover 1
16 WE125-301070781 Handle Knob & Nut 2 51 WE125-104030135 St4.2*12 Screw 4
17 WE125-103020129 Lower Handle 1 52 WE125-103060289-1 Tension Spring 1
18 WE124-301070910 Motor Cover 1 53 WE125-103990750 Pin 1
19 WE124-301070911 Air Window Cover 1 54 WE125-103990798 Front Connecting Rod 1
20 WE124-301070396F Motor Cover Carry Handle 1 55 WE125-301062854 Adjusting Bracket 1
21 WE125-301070920 Upper Deck 1 56 WE125-301062853 Long Pin Shaft 1
22 WE125-4070213 Motor Assembly 1 57 WE125-103050261 Adjusting Bracket Shaft 1
23 WE125-104030423 St4.2X18 Screw 7 58 WE125-103060285 Torsional Spring 1
24 WE125-104030300 M5×12 Screw 2 59 WE125-104010257 Washer 7
25 WE125-103990881 Height Adjuster Back Plate 1 60 WE125-301070794 Blade Support Plate 1
26 WE125-105020068 Gland 1 61 WE125-103030127 Blade 1
27 WE125-104020017 Locknut 2 62 WE124-104040205 Frange Bolt 1
28 WE124-103050242 Shield Bearing 1 63 WE125-103050274 Front Axle 1
29 WE125-104020077 Hex Nut 2 64 WE125-301062850 Front Wheel 2
30 WE125-301070921 Upper Deck 1 65 WE125-301062849 Front Wheel Trip 2
31 WE125-301070902 Lower Handle Adjuster 2 66 WE124-301070580P Collector Carry Handle 1
32 WE125-104040215 Adjusting Bolt 2 67 WE124-301062859 Flip 1
33 WE124-104050028 Split Washer 2 68 WE124-301070917 Collector Top 1
34 WE124-103050260 Grass Flap Axle 1 69 WE125-105011067 Lower Collector 1
35 WE124-103060300 Torsional Spring 1 70 WE125-301990135 Pressing Line Plate 1
