PARTS LIST – WEER40 (1938124001)
Item
No.
Part No. Description Qty
Item
No.
Part No. Description Qty
1 WE126-4080061 Switch Box Assembly 1 37 WE126-301070903 Grass Flap 1
2 WE125-103080036 Upper Handle 1 38 WE126-301062836 Rear Wheel 2
3 WE125-301062831 Switch Box Small Cover 1 39 WE125-104010258 Washer 7
4 WE125-103990876 Operator Handle 1 40 WE125-104050024 Split Washer 4
5 WE125-301070717 Left Permanent Seat 1 41 WE126-301062835 Rear Wheel Trim 2
6 WE125-301062827 Left Clamp 1 42 WE125-301062852 Height Adjuster 1
7 WE125-104040082 M4*8 Bolt 3 43 WE126-103990877 Height Adjuster Lever 1
8 WE125-301070716 Left Fixed Cover 1 44 WE125-104030203 M4*8 Bolt 2
9 WE125-104030136 ST4.2X15BT Screw 21 45 WE126-103020148 Collection Bag Frame 1
10 WE125-301070806 Cable Clip 2 46 WE125-301062851 Pin Shaft 2
11 WE125-301070899 Quick Release Handle 4 47 WE125-103990799 Rear Connecting Rod 1
12 WE125-103990795 Spring Pin 4 48 WE125-103990811 Split Pin 3
13 WE125-104040202 M8×73 Bolt 2 49 WE124-103990797 Axle Clamp 6
14 WE125-301070779 Quick Release Support 2 50 WE126-301070797 Housing Insert 1
15 WE125-301070780 Washer 2 51 WE125-104030135 ST4.2*12BT Screw 4
16 WE125-301070781
Handle Knob wirh M8 Nut 2 52 WE125-103060289-1 Tension Spring 1
M8 Nut 2 53 WE125-103990750 Pin 1
17 WE126-103020127 Lower Handle 1 54 WE125-103990798 Front Connecting Rod 1
18 WE124-301070910 Motor Cover 1 55 WE126-301070796 Adjusting Aracket 1
19 WE124-301070911 Air Window Cover 1 56 WE125-301062853 Long Pin Shaft 1
20 WE124-301070396f Motor Cover Carry Handle 1 57 WE126-103050254 Adjusting Bracket Shaft 1
21 WE126-301070900 Upper Deck 1 58 WE125-103060285 Height Adjuster Spring 1
22 WE126-4070214 Motor Assembly 1 59 WE125-104010257 Washer 7
23 WE125-104030423 ST4.2x18 BT Screw 7 60 WE124-103050242 Bearing 1
24 WE126-301070901 Front Bumper 1 61 WE125-301070794 Blade Support Plate 1
25 WE125-104030300 M5×12 Screw 2 62 WE126-103030128 Blade 1
26 WE126-103990796 Height Adjuster Back Plate 1 63 WE124-104040205 M8*20 Blade Bolt 1
27 WE126-105020065 Height Adjuster Frame 1 64 WE126-103050273 Front Axle 1
28 WE125-104020017 M5 Lock Nut 2 65 WE125-301062850 Front Wheel 2
29 WE125-104020077 M8x8 Nut 2 66 WE125-301062849 Front Wheel Trim 2
30 WE126-301070789 Lower Deck 1 67 WE124-301070580P Collector Carry Handle 1
31 WE125-301070902 Lower Handle Adjuster 2 68 WE124-301062859 Flip 1
32 WE125-104040215 M8×63 Bolt 2 69 WE126-301070904 Collector Top 1
33 WE126-104050022 Split Washer 2 70 WE126-105011065 Collection Bag 1
34 WE126-103050256 Grass Flap Axle 1 71 WE125-301990135 Pressing Line Plate 1
35 WE126-103060290 Grass Flap Spring 1 72 WE126-301070905 Collection Bag Plug (L) 1
36 WE126-10305272 Rear Axle 1 73 WE126-301070906 Collection Bag Plug (R) 1
PARTS DIAGRAM – WEER40 (1938124001)
