Webb WEPS400 - Page 27

PARTS LIST - WEPS400 1938317002 - MACHINE
Item No.
Webb Part No.
Webb Description
Qty
1
WE182-94294
Flat Washer 30x10.5x2.5
5
2
WE182-632001
Scarifier Blade Cartridge
1
3 WE182-632007 Mounting Cover 2
4 WE182-93037 Bearing 2
5
WE182-632006
Bearing Mounting Block
1
6
WE156-91325
M6x12 Bolt
6
7
WE182-636015
Blade Pulley
1
8
WE150-91329
M6x16 Bolt
6
9
WE182-635006
Spring
1
10 WE153-90061 Nut M6 1
11 WE149-90059 Nut M8 12
12
WE182-91927
Step Bolt
1
13
WE149-90057
Nut M10x1.5
5
14
WE201-94207
Flat Washer 13x37x4
1
15 WE165-606140 Wheel 4
16 WE182-606060 Bolt M10 2
17
WE182-606144-198
Wheel Trim
4
18
WE182-91322
Bolt M5x12
4
19
WE182-636004
Front Axle Bush
4
20
WE201-90063
Nut M5
4
21 WE182-636001 Front Axle 1
22 WE182-606007 Belt 1
23
WE149-94041
Washer 8.4x24x2
7
24
WE182-636016-010
Belt Cover
1
25
WE182-90075
Nut M10x1.5
2
26
WE182-636014
Belt Pulley
1
27 WE153-90058 Nut M6 1
28 WE201-94025 Washer 6.4x18x1.6 1
29
WE182-91228
Belt Pulley Bolt
1
30
N/A
212cc ENGINE DH/DVO212
1
31
WE182-94261
Gasket 8.4x16x1
1
32
WE182-92107
Bolt M8x30
4
33 WE182-631002 Engine Mounting Plate 1
34 WE149-94057 Washer 8 1
PARTS DIAGRAM - WEPS400 1938317002 - MACHINE
Item No.
Webb Part No.
Webb Description
Qty
35 WE149-94040 Spring Washer 8.1x2.1 5
36 WE201-91349 Bolt M8x40 4
37 WE182-92113 Bolt M10x130 1
38
WE182-636002
Rear Wheel Bolt
2
39
WE182-636003
Rear Axle Sleeve
2
40
WE153-91881
Bolt M8x16
4
41 WE182-631003 Left Handle Bracket 1
42 WE182-631008-333 Deck 1
43
WE153-94036
Circlip 5
2
44
WE182-634001
Rear Grass Flap
1
45
WE182-634002
Rear Grass Flap Spring
2
46
WE182-634003
Rear Grass Flap Shaft
1
47
WE182-634004
Right Handle Bracket
1
48 WE182-633001 Height Adjustment Lever 1
49 WE182-633003 Height Adjustment Rod 1
50
WE182-632005
Bearing Cover
1
51
WE182-91926
Step bolt
1
52
WE182-633002
Height of Cut Board
1
53
WE182-634005
Collector Frame
1
54 WE182-634004-057 Collector Bag 1
55 WE182-635001-206 Lower Handle 1
56
WE182-605159
Cable Clip
1
57
WE160-605098-198
Triangle Knob (Grey)
2
58
WE182-605008-206
Upper Handle
1
59 WE182-635003 OPC/Brake Cable 1
60 WE153-91870 Bolt M6x35 1
61 WE201-605010-136 OPC Brake Lever 1
62
WE201-90060
Nut M6
2
63
N/A
Soft Grip Handle (Comes with 58)
1
64
WE153-91868
Bolt Mx45
2
65 WE182-90050 M10 Nut 1
66 WE201-91331 Bolt M6x25 1
67
WE201-94205
Spring Washer Φ6
1
68
WE182-632008
Aerator Sprung Cartridge
1
Not all componets are availabile singularly and may only be available as part of an assembly of components.
Please contact our Spares Team Tel: 01793 333212, option 1 or spares@handys.co.uk for assistance.
PARTS LIST - WEPS400 1938317002 - MACHINE
Item No.
Webb Part No.
Webb Description
Qty
1
WE182-94294
Flat Washer 30x10.5x2.5
5
2
WE182-632001
Scarifier Blade Cartridge
1
3
WE182-632007
Mounting Cover
2
4
WE182-93037
Bearing
2
5
WE182-632006
Bearing Mounting Block
1
6
WE156-91325
M6x12 Bolt
6
7
WE182-636015
Blade Pulley
1
8
WE150-91329
M6x16 Bolt
6
9
WE182-635006
Spring
1
10
WE153-90061
Nut M6
1
11
WE149-90059
Nut M8
12
12
WE182-91927
Step Bolt
1
13
WE149-90057
Nut M10x1.5
5
14
WE201-94207
Flat Washer 13x37x4
1
15
WE165-606140
Wheel
4
16
WE182-606060
Bolt M10
2
17
WE182-606144-198
Wheel Trim
4
18
WE182-91322
Bolt M5x12
4
19
WE182-636004
Front Axle Bush
4
20
WE201-90063
Nut M5
4
21
WE182-636001
Front Axle
1
22
WE182-606007
Belt
1
23
WE149-94041
Washer 8.4x24x2
7
24
WE182-636016-010
Belt Cover
1
25
WE182-90075
Nut M10x1.5
2
26
WE182-636014
Belt Pulley
1
27
WE153-90058
Nut M6
1
28
WE201-94025
Washer 6.4x18x1.6
1
29
WE182-91228
Belt Pulley Bolt
1
30
N/A
212cc ENGINE DH/DVO212
1
31
WE182-94261
Gasket 8.4x16x1
1
32
WE182-92107
Bolt M8x30
4
33
WE182-631002
Engine Mounting Plate
1
34
WE149-94057
Washer 8
1
Item No.
Webb Part No.
Webb Description
Qty
35
WE149-94040
Spring Washer 8.1x2.1
5
36
WE201-91349
Bolt M8x40
4
37
WE182-92113
Bolt M10x130
1
38
WE182-636002
Rear Wheel Bolt
2
39
WE182-636003
Rear Axle Sleeve
2
40
WE153-91881
Bolt M8x16
4
41
WE182-631003
Left Handle Bracket
1
42
WE182-631008-333
Deck
1
43
WE153-94036
Circlip 5
2
44
WE182-634001
Rear Grass Flap
1
45
WE182-634002
Rear Grass Flap Spring
2
46
WE182-634003
Rear Grass Flap Shaft
1
47
WE182-634004
Right Handle Bracket
1
48
WE182-633001
Height Adjustment Lever
1
49
WE182-633003
Height Adjustment Rod
1
50
WE182-632005
Bearing Cover
1
51
WE182-91926
Step bolt
1
52
WE182-633002
Height of Cut Board
1
53
WE182-634005
Collector Frame
1
54
WE182-634004-057
Collector Bag
1
55
WE182-635001-206
Lower Handle
1
56
WE182-605159
Cable Clip
1
57
WE160-605098-198
Triangle Knob (Grey)
2
58
WE182-605008-206
Upper Handle
1
59
WE182-635003
OPC/Brake Cable
1
60
WE153-91870
Bolt M6x35
1
61
WE201-605010-136
OPC Brake Lever
1
62
WE201-90060
Nut M6
2
63
N/A
Soft Grip Handle (Comes with 58)
1
64
WE153-91868
Bolt Mx45
2
65
WE182-90050
M10 Nut
1
66
WE201-91331
Bolt M6x25
1
67
WE201-94205
Spring Washer Φ6
1
68
WE182-632008
Aerator Sprung Cartridge
1
Not all componets are availabile singularly and may only be available as part of an assembly of components.
Please contact our Spares Team Tel: 01793 333212, option 1 or spares@handys.co.uk for assistance.
