TILLER HEIGHT ADJUSTMENT
CAUTION
Before adjusting the handle, place the tiller on firm level ground to prevent the handle from collapsing
accidentally.
• To adjust the tiller height, loosen the adjuster, select the appropriate hole and tighten the adjuster.
TILLER DEPTH ADJUSTMENT
• Install the hitch attachment in the hitch box with a hitch pin.
• The tilling depth adjustment can be made as follows:
• Remove the hitch bar locking pin, sliding the drag bar up or down as necessary.
CLUTCH LEVER
• The clutch engages and disengages the power from the engine to the transmission.
• When the clutch lever is squeezed, the clutch is engaged, and power is transmitted. Squeeze the lever,
the tines will be rotated.
• When the lever is released, the clutch is disengaged and power is not transmitted, release the clutch
lever, the tool will be stopped.
