Item No. Webb Part No. Description Qty Item No. Webb Part No. Description Qty
1 WE149‐661002 Handle Housing 1 31 WE149‐91349 M8x40 Bolt 1
2 WE149‐91441 M5x35 Bolt 1 32 WE149‐661009‐039 Cl utch Lever 1
3 WE149‐666005 Right Tine Assembly 1 33 WE149‐661007 Clutch Cable 1
4 WE149‐662001 Gearbox 1 34 WE149‐661005‐206 Left Handle 1
5 WE149‐90063 M5 Nut 1 35 WE149‐661004 Handle Grip 2
6 WE149‐666002 Cover 2 36 WE149‐90059 M8 Nut 1
7 WE149‐816004 Circlip Φ2 3 37 WE149‐90043 M6 Nut 1
8 WE149‐666006 Left Ti ne Ass embl y 1 38 WE149‐94011 Washer Φ12 1
9 WE149‐661010 Clutch Spring 1 39 WE149‐605031 Throttle Lever Cover (L) 1
10 WE149‐91899 Clevis Pin with Head 8x35 2 40 WE149‐605012‐039 Throttle Lever 1
11 WE149‐665003 Front Wheel 1 41 WE149‐605032 Throttle Lever Cover (R) 1
12 WE149‐94068 Nylon Washer 2 42 WE149‐91869 M6x44 Bolt 1
13 WE149‐665002 Bolt 1 43 WE149‐661003‐206 Right Handle 1
14 WE149‐665001 Wheel Housing 1 44 WE149‐661006 Throttle Cable 1
15 WE149‐91888 M10x65 Bolt 1 45 WE149‐605004 Cable Clip 2
16 WE149‐90057 M10 Nut 2 46 WE149‐91881 M8x16 Bolt 4
17 WE149‐665005 Spring 1 47 WE149‐91348 M8x35 Bolt 1
18 WE149‐91346 M8x25 Bolt 10 48 WE149‐94041 Washer Φ8.4X24X2 11
19 WE149‐662056 Belt VZ610 1 49 WE149‐94040 Washer 8.1X2.1 17
20 WE149‐91891 Bolt 3/8UNFX30 1 50 WE149‐661001‐333 Handle Base 1
21 WE149‐94270 Washer Φ10.5X30X2.5 1 51 WE149‐666018 Circlip 1
22 WE149‐662007 Small Pulley 1 52 WE149‐662005 Large Pull ey 1
23 WE149‐94273 Washer Φ10 (GB97) 1 53 WE149‐94289 Washer Φ13.2×Φ24×1.5 1
24 WE149‐296511 Fl at Key 1 54 WE149‐662038‐333 Gearbox Base 1
25 WE149‐662006‐333 Belt 1 55 WE149‐666003 Depth Gauge 1
26 WE149‐91347 M8x30 Bolt 7 56 WE149‐662003 Tension Pulley 1
27 WE149‐663025 Engine Housing 1 57 WE149‐662004 Spring 1
28 WE149‐90018 M8 Nut 8 58 WE149‐94057 Washer Φ8 4
29 WE149‐230016010021 Engine 1 59 WE149‐663002‐333 Fender 1
30 WE149‐661011 Clutch Spring 1
