15
OPERATION
ENGINE STARTING & STOPPING PROCEDURE
STARTING THE ENGINE - COLD
1. Press the engine primer bulb up to 3 times.
2. Pull the OPC/brake lever towards the top handle.
3. Grab the recoil starter handle and pull lightly until resistance is felt, then pull rapidly.
CAUTION
Do not allow the starter grip to snap back against
the engine. Return it gently to prevent damage to
the starter.
STARTING THE ENGINE - WARM
1. Pull the OPC/brake lever towards the top handle.
2. Grab the recoil starter handle and pull lightly until resistance is felt, then pull rapidly.
CAUTION
Do not allow the starter grip to snap back against
the engine. Return it gently to prevent damage to
the starter.
ADD ENGINE OIL
Only use 4-stroke SAE30 or 10W/30 air cooled lawnmower engine oil. DO NOT USE automotive or marine oil.
1. Remove the oil filler cap with built in dipstick (G).
2. Fill the engine with 4-stroke SAE30 or 10W/30 air cooled lawnmower engine oil. DO NOT USE automotive
or marine oil. The use of a funnel will aid the filling.
3. The engine capacity is 0.40L, however we recommend the dipstick on the oil filler is dipped (without
screwing into the filler neck) to ensure the oil level remains between the minimum and maximum marks
on the dipstick.
ADJUSTING THE TRIMMER SPINDLE HEIGHT
The trimmer spindle height can be adjusted for various applications. To do so, proceed as follows:
1. Loosen the bolt found on each side of the spindle shaft (1).
Note: The bolts are designed so that they cannot be removed from the spindle shaft.
2. Slide the spindle up or down to the desired position before retightening the bolts (1) and nuts (2).
Note: The bolts must be tightened on the spindle before starting the equipment.
AMBIENT TEMPERATURE
OIL RECOMMENDATIONS
