PARTS DIAGRAM - WEPWT 1938259001
PARTS LIST - WEPWT 1938259001
Item No.
Webb Part No.
Webb Description
Qty
1
WE153-90058
M6 Nut
3
2
WE178-624015
Bump Head
1
3
WE149-94040
Spring Washer
1
4
WE178-96812
Flat Gasket
1
5
WE178-624012
Bearing
2
6
WE178-624013
Driven Jackshaft
1
7
WE156-91325
M6x12 Bolt
4
8
WE178-624016
Shaft Sleeve
1
9
WE178-622001
4mm Trimmer Line
2
10
WE149-91346
M8x25 Bolt
2
11
WE178-90011
M8 Nut
2
12
WE178-624014
Plate Assembly
1
13
WE178-94096
Washer
1
14
WE178-624011
Driven Cutting Pulley
1
15
WE178-94097
Spacer
1
16
WE178-94095
Washer
1
17
WE178-621001-010
Cutting Deck
1
18
WE178-624001
Wheel
2
19
WE153-94046
Flat Washer
2
20
WE178-624003
Axle Jackshaft
1
21
WE178-624002
Rear Axle
1
22
WE178-91979
Bolt M8x25
6
23
WE149-91891
Bolt 3/8UNFX30
1
24
WE153-94042
Flat Washer
1
25
WE178-624005
Engine Pulley
1
26
WE178-296514
Crankshaft Flat Key
1
27
WE178-DVO165
ENGINE
1
28
WE178-623006V-010
Lower Handle Left
1
29
WE153-605006
Stem
2
30
WE178-623002V-010
Middle Handle
1
31
WE178-623005V-010
Lower Handle Right
1
Item No.
Webb Part No.
Webb Description
Qty
32
WE153-91868
Bolt M8x45
4
33
WE153-91870
Bolt M6x35
1
34
WE178-623003V-010
OPC/Brake Lever
1
35
WE178-623004
OPC/Brake Cable
1
36
WE178-623001V-010
Top Handle (with 62)
1
37
WE153-90061
NUT M6
2
38
WE153-605009
Rope Guide Support
1
39
WE149-94041
Washer 8.4x24x2
4
40
WE178-605098
Triangle Knob (Black)
4
41
WE153-605221
Cable Clip
1
42
WE149-91347
M8x30 Bolt
4
43
WE149-90059
Nut M8
10
44
WE154-94049
Circlip
1
45
WE178-624004
Wheel Spacer
1
46
WE149-90057
M10 Nut
2
47
WE178-621002
Rear Shield
1
48
WE178-624009
Tension Wheel Bush
1
49
WE178-624008
Tension Wheel
1
50
WE178-624007
Tension Spring
1
51
WE178-622003-010
Cutting Shield
1
52
WE159-92068
Screw M6x10
2
53
WE178-622004-010
Small Cutting Shield
1
54
WE178-91436
Bolt M5x8
2
55
WE178-622002
Cutting Knife
1
56
WE149-90063
M5 Nut
2
57
WE153-90060
Nut M6
4
58
WE178-624006
Belt
1
59
WE158-91406
Bolt M6x14
4
60
WE178-624010
Driveshaft
1
61
WE156-91345
M8x20 Bolt
1
62
See 36
Soft Grip
1
