Weber mt CF 2 - 1. Technical Description; 1.1 Illustration

6
1
1
1
1
2
SERVICE INFORMATION
Repair manual CF 2 + CF 3
Screw the screws (1) into the threaded holes
of the housing cover and push the housing cover
out of the housing.
Take the eccentric shaft (1) out of the exciter housing.
Housing cover (1)
Paper seal (2)
Remove the fastening screws of the housing cover.
