Find the Strongest Signal Install Inside Window Mount Cradle Insert the Outside Antenna into the Cradle
Connect Coax Cable to Outside Antenna Connect Cables to Home 4G Connect to Power Supply
Select a location on the inside of a window as high as possible and
at least 20 feet from where the DT4G will be located. Note that this
distance typically requires the window mount to be in a different
room from where you will locate the DT4G and Desktop Antenna.
The window should face roughly in the direction of the strongest
cellular signal.
Clean the area on the glass with the alcohol prep pad (included).
Press the suction cups onto the window in the desired location.
Insert the Outside Antenna into the cradle.
Connect the supplied coax cable to the antenna lead cable on the
Outside Antenna. Route the cable as desired to the location of the
Home 4G. If you need to connect both coax cables, use the Cable
Connector provided.
Connect the coax cable to the Home 4G. Connect the Desktop
Antenna to the Home 4G.
Connect the AC Power Supply to the Home 4G then to a surge
protected AC power strip with at least a 1000 Joule rating. If your
Home 4G is working correctly, the lights will be green.
1 2 3
4 5 6
window faces general
direction of cell tower
Full diagram on opposite side
Power Supply
Surge Protected
Power Strip
Outside Panel Antenna
Press Cradle onto
window
Cable Connector
Home 4G
Desktop Antenna
