Weh TW01 - Page 11

TW01 for threaded application
Pos� Description
1 Housing
2 Spacer
7 Front seal
8 Main seal
Definition of ports
B1
Media inlet
P1
Pilot pressure port - inlet
G
Mounting bore
G
B1
G
P1
7
2
1
8
