Weh TW01 - Page 12

TW01 twin connectors for non-threaded application holes
Pos� Description
1 Housing
2 Spacer
7 Front seal
Definition of ports
B1
Media inlet
P1
Pilot pressure port - inlet
G
Mounting bore
7
2
1
G
B1
G
P1
B1
MD-10187-L51-R1.3.0-03
Page 12
Operating instructions
AE
