Weh TW01 - Page 13

Product description accessories
Pneumatic coupling and control-/ bleeding valve
Pos� Description
3 Control-/ bleeding valve
4 Pneumatic coupling
Definition of ports
P1
Pilot pressure port - inlet
P2
Pilot pressure port - outlet
Hand slide valve and thread extension
Pos� Description
5 Thread extension
6 Hand slide valve
Definition of ports
P1
Pilot pressure port - inlet
P2
Pilot pressure port - outlet
Elbow 90°
Definition of ports
P1
Pilot pressure port - inlet
P2
Pilot pressure port - outlet
3
4
P1
P2
5
6
P1
P2
P1
P2
P1
P2
MD-10187-L51-R1.3.0-03
Page 13
Operating instructions
AE
