9�4�2 Replacement of seals for threaded applications
General information
Î
Check the back-up washers for deformation, corrosion and wear even if you are only
replacing the seals.
Î
Replace the complete main seal set if the back-up washers are deformed, corroded
or worn.
Î
Always replace the retaining ring when replacing the main seal.
- The TW01 main seal set for threaded applications contains the polyurethane main
seal(s) (Pos. 8), back-up washer(s), a retaining ring, a NBR front seal (Pos. 7) and a
seal mount for the front seal.
Body size
Number of
front seals
*
Number of
back-up washers
Number of
retaining rings
Number of
seal mount
01 2 1 1 1
1, 2, 3, 4 2 2 1 1
5, 6 3 2 1 1
*
Main seal(s) made of polyurethane, front seal made of NBR
MD-10187-L51-R1.3.0-03
Page 30
