Weider WEBE03820 User Manual

This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
each part refers to the key number of the part from the PART LIST in the center of this manual. Important:
Some parts may have been pre-assembled for shipping purposes. If you cannot find a part in the parts
bags, check to see if it has been pre-assembled.
M8 Nylon Locknut (17)
M6 x 16mm Screw (29)
M10 Nylon Locknut (33)
M10 x 60mm Bolt (32)
M6 x 38mm Screw (30)
M8 Washer (16)
M10 Washer (34)
M10 x 115mm Bolt (19)
M8 x 55mm Bolt (18)
M6 Washer (26)
M10 x 135 mm Bolt (36)
M10 x 55mm Bolt (42)
M8 x 50mm Carriage Bolt (52)
M8 x 40mm Carriage Bolt (46)
M8 x 16mm Bolt (45)
PART IDENTIFICATION CHART
