Weider WEBE15420 - Part Identification Chart

5
M10 Washer (29)
M6 Washer (26)
M8 Nylon Locknut (25)
M8 x 58mm Carriage Bolt (36)
M6 x 62mm Screw (38)
M8 x 68mm Bolt (22)
M8 x 60mm Bolt (30)
M10 x 168mm Bolt (8)
M6 x 38mm Screw (14)
M10 x 64mm Bolt (12)
M8 Washer (10)
M10 Nylon Locknut (11)
M6 x 16mm Screw (31)
M10 x 19mm Bolt (48)
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST on page 14 of this manual. Note: Some small parts may
have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
PART IDENTIFICATION CHART
