Weider WEBE17100 - Part Identification Chart

5
This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
each part refers to the key number of the part. The second number refers to the quantity needed for assembly.
Important: Some parts may have been pre-assembled for shipping purposes. If you cannot find a part in
the parts bags, check to see if it has been pre-assembled.
M10 x 81mm Bolt (43)Ñ10
M8 x 58mm Bolt (49)Ñ1
Narrow Spacer (30)Ð1
M6 x 16mm Screw (15)Ñ6
M10 x 178mm Bolt (17)Ñ1
M10 x 65mm Bolt (18)Ñ5
M8 Nylon Locknut (13)Ñ2
M8 Washer (48)Ñ2
M10 Nylon Locknut (19)Ñ20
M6 Washer (25)Ñ4
M10 Washer (24)Ñ12
M10 x 67mm Bolt (14)Ñ2
M10 x 19mm Bolt (46)Ñ1
M10 x 72mm Bolt (53)Ñ1
M4 x 16mm Screw (42)Ñ4
M8 x 70mm Bolt (54)Ñ1
Wide Spacer (47)Ð2
M6 x 38mm Screw (16)Ñ4
Part Identification Chart
