6
COLUMN, TABLE, BASE ASSEMBLY
Parts No. Description Specification Qty Code NO.
1 Vertical Slide 1 30211201
2 Screw M6×16 2 50618864A
3 Washer Ɏ8 6 50637908
4 Spring Washer Ɏ8 6 50637808
5 Hex Head Cap Screw M8×25 2 50619073
6 Washer Ɏ12 1 30213202
7 Spring Washer Ɏ12 5 50637812
8 Screw M12×40 1 50612864
9 T-Bolt M8×60 3 50611323
10 Washer Ɏ8 3 30211203
11 Spring Washer Ɏ8 3 50637808
12 Nut M10 3 50630210
13 Block 1 30211204
14 Brass Pin Ɏ5×10 6 30212206
15 Locking Lever M6×16 4 50661063
16 Postion label 5 3L922001
17 Rivet 2×3 16 50626720
18 Gib Screw 6 30212207
19 Gib 1 30211208
20 Angle Indicate Label 1 30211903
21 Hex Head Cap Screw M5×10 12 50619051B
22 Dust Cover 120×400mm 1 30212209
23 Nut M
5 2 50634805
24 Bracket 1 30211210
25 Dust Cover 1 30211211
26 Connect Plate 1 3021
30211201
30211202
1212
27 Nut
28 Handle M6x50 1 302132232
29 Handwheel 1
30 Dial 1 30213214
31 Bearing 51203 1 50451203
To Next Page
