7/16"
9-1/5"
234mm
Model
Max. Drilling Capacity 11/16" 18mm
Max. End Milling Capacity 5/8" 16mm
Max. Face Milling Capacity 1-31/32" 50mm
T-Slot Size 3 @ 25/64" slots 3 @ 10mm slots
T-Slot Centers 1-3/8" 35mm
Table Size
19-11/16" × 5-
500 × 140mm
Table Travel (X,Y) 8-21/32" × 6-19/64" 220 × 160mm
X/Y-Axis Travel per Handwheel
Revolution
Spindle Stroke 1-31/32" 50mm
Distance from Spindle to Column 6-11/16" 170mm
Distance from Spindle nose to
10-53/64" 275mm
Drawbar Thread Size
Drawbar Length
Head Tilt (Left/Right)
Spindle Taper
Number of Spindle Speeds
Vertical Spindle Speeds
Motor Type
Power Requirement
Rated Current
Packing Size
Net Weight
Gross Weight
10A
Single Phase 110V 60Hz
100 - 2250 RPM
196.2 lbs.
20" × 21-1/4" × 32-7/8"
154.4 lbs.
0.1"
VM18L
Brushless 1HP
90 Deg.
R8
Variable
33/64"
table
