Page #21 background imageLoading...
Page #21 background image
Parts No. Description Specification Qty Code NO.
61 Handle M8×63 2 30213223
62 Handwheel 2 30213306
63 Dial 2 30212307
64 Bearing 51200 3 50451200
65 Longitudinal Leadscrew WMD16V 1 30211308
Longitudinal Leadscrew(L) WMD16LV 1 30211308L
66 Hex Head Cap Screw M6×10 4 50619058B
67 Bush Ɏ15 45#steel 2 30212309
68 Nut 2 30212310
69 Scale 1 30211905
70 Longitudinal Nut 1 30211311
71 Adjusted Screw M4×14 4 50619044
72 Cross Slide 1 30211312
73 Position Block 1 30211313
74 Cross Gib 1 30211314
75 Cross Nut 1 30211315
76 Longitudinal Gib 1 30211316
77 Locking Lever M6×25 2 50661065
78 Hex Head Cap Screw M6×25 4 50619064
79 Bearing 51100 2 50451100
80 Bearing Housing 1 30211317
81 Cross Leadscrew 1 30211318
8
2 Base 1 30211319
8
