16
Operating data SR65 Step 1* Step 2 * Step 3* Step 4 Step 5 Step 6
Speed 1/min 140 175 205 240 270 305
Drill Ø concrete mm 330 - 500 270 - 440 230 - 370 200 - 320 175 - 280 125 -250
Water supply l/min 2,2 - 2,7 2 - 2,5 1,8 - 2,3 1,7 - 2,1 1,6 - 2 1,3 - 1,9
Operating data SR68 - Gear step 1
Motor step/Speed 1/min 1/205 2/245 3/290 4/340 5/400 6/450
Drill Ø concrete mm 350 275 235 200 170 150
Water supply l/min 1,9 1,7 1,5 1,4 1,3 1,2
Operating data SR68 - Gear step 2
Motor step/Speed 1/min 1/410 2/480 3/570 4/670 5/790 6/880
Drill Ø concrete mm 165 140 120 100 85 75
Water supply l/min 1,3 1,2 1,1 1,0 0,9 0,9
Operating data SR68 - Gear step 3
Motor step/Speed 1/min 1/640 2/750 3/880 4/1040 5/1230 6/1370
Drill Ø concrete mm 105 90 75 65 55 50
Water supply l/min 1,0 0,9 0,9 0,8 0,7 0,7
Operating data SR75 - Gear step 1
Motor step/Speed 1/min 1/60* 2/70 3/85 4/100 5/115
Drill Ø concrete mm 950 950 800 670 580
Water supply l/min 3,1 3,1 2,8 2,6 2,4
Operating data SR75 - Gear step 2
Motor step/Speed 1/min 1/115* 2/140 3/165 4/200 5/230
Drill Ø concrete mm 500 500 410 340 290
Water supply l/min 2,2 2,2 2,0 1,8 1,7
Operating data SR75 - Gear step 3
Motor step/Speed 1/min 1/180* 2/215 3/260 4/310 5/360
Drill Ø concrete mm 320 320 260 220 150
Water supply l/min 1,8 1,8 1,6 1,5 1,2
Operating data SR75 S - Gear step 1
Motor step/Speed 1/min 1/75* 2/90 3/105 4/130 5/150
Drill Ø concrete mm 800 750 630 520 450
Water supply l/min 2,8 2,7 2,5 2,3 2,1
Operating data SR75 S - Gear step 2
Motor step/Speed 1/min 1/150* 2/175 3/210 4/250 5/290
Drill Ø concrete mm 450 380 320 260 230
Water supply l/min 2,1 1,9 1,8 1,6 1,5
Operating data SR75 S - Gear step 3
Motor step/Speed 1/min 1/230* 2/280 3/330 4/390 5/460
Drill Ø concrete mm 290 240 200 170 140
Water supply l/min 1,7 1,5 1,4 1,3 1,2
* These gears are power-reduced.
Holes of more than Ø 250 mm can only be produced with particularly stable rigs and the use of heavy
duty dowels for fastening.
Holes with the SR65/68/75 can only be made with especially appropriate, extremely stable and safe drill
rigs. The SR75 therefore has in any case to be fixed with 8 screws at the drill rig, the SR65 with 6 screws.
Please note that the machine develops a nominal torque of up to 700 Nm and that the
torque can increase up to 1000 Nm when the drill bits jams in the hole.
3.2 Scope of delivery
Diamond core drilling machine (1) with ball valve and water connect nipple (1a), and operating
instructions.
3.3 Noise emissions and vibration (EN 62841)
SR25/38 SR65/68/75
The typical A-rated sound pressure level is 75 dB(A) 80 dB(A)
The typical A-rated sound level is 88 dB 92 dB
The typical rated acceleration is 2,5 m/s² 2,5 m/s²
