Deluxe Display – Stand Alone – Alarms & Variables Menu
ACCESS THE ALARMS MENU. Use the or to scroll through the Alarms & Variables menu. Note: Alarms will display first, if no alarms
are active only the Variables are displayed.
NAME
DESCRIPTION
ROOMTEMP2 SENSOR ALARM Temp 2 input is shorted or open
ROOMTEMP3 SENSOR ALARM Temp 3 input is shorted or open
MONITOR TEMP2 SENSOR ALARM Temp 2 input is shorted or open
HIGH MONITOR TEMP2 ALARM Temp 2 input is above High Temp Alarm Offset for longer than High Temp Alarm Delay.
LOW MONITOR TEMP2 ALARM Temp 2 below Low Temp Alarm Offset for longer than Low Temp Alarm Delay.
MONITOR TEMP3 SENSOR ALARM Temp 3 input is shorted or open
HIGH MONITOR TEMP3 ALARM Temp 3 input is above High Temp Alarm Offset for longer than High Temp Alarm Delay.
LOW MONITOR TEMP3 ALARM Temp 3 below Low Temp Alarm Offset for longer than Low Temp Alarm Delay.
DOOR OPEN ALARM Door has been open longer than Door Alarm Delay
DOOR TEMP SENSOR ALARM Temp1 input is shorted or open
LOW DOOR TEMP ALARM Door Temp is below Low Door Alarm Offset for longer than Door Temp Alarm Delay
HIGH DOOR TEMP ALARM Door Temp is above High Door Alarm Offset for longer than Door Temp Alarm Delay
EXTERNAL ALARM 1, 2, OR 3 If input is selected as external alarm, and alarm becomes active
TEMP 2 READING
Toggle between Temp2 and value read by controller, if ‘DOOR SWITCH’ selected, ‘T2 DOOR
CLOSED, TS DOOR OPEN’ if ‘EXTERNAL ALARM’ selected, ‘T2 EXT ALARM ACTIVE, T2 NO
EXT ALARM
The range is -87.7 to 183.0 degrees F. If there is a sensor failure, value will read 888.8. Will
report T2 DOOR CLOSED if reads that door is closed, T2 DOOR OPEN if reads that door is
open. Will report T2 EXT ALARM ACTIVE if reads that alarm is active, T2 NO EXT ALARM if
reads alarm is inactive
TEMP 3 READING
Toggle between TEMP3 and value read by controller. if ‘DOOR SWITCH’ selected, ‘T3 DOOR
CLOSED, T3 DOOR OPEN’ if
‘EXTERNAL ALARM’ selected, ‘T3 EXT ALARM ACTIVE, T3 NO EXT ALARM
The range is -87.7 to 183.0 deg F. If there is a sensor failure, value will read 888.8. Will
report T3 DOOR CLOSED if reads that door is closed, T3 DOOR OPEN if reads that do CTIVE
if reads that alarm is active, T3 NO EXT ALARM if reads alarm is inactive
DOOR TEMP READING
Toggle between TEMP1 and value read by controller. if ‘DOOR SWITCH’ selected, ‘T1 DOOR
CLOSED, T1 DOOR OPEN’ if
‘EXTERNAL ALARM’ selected, ‘T1 EXT ALARM ACTIVE, T1 NO EXT ALARM
The range is -87.7 to 183.0 deg F. If there is a sensor failure, value will read D888. Will
report T1 DOOR CLOSED if reads that door is closed, T1 DOOR OPEN if reads that do CTIVE
if reads that alarm is active, T1 NO EXT ALARM if reads alarm is inactive
DOOR SWITCH STATE
DOOR CLOSED, DOOR OPEN, DOOR SWITCH DISABLED
Will report DOOR CLOSED if reads r is open, DOOR SWITCH DISABLED if door switch
function is disabled
