SPECIFICATIONS
IOM-089 Page 4 of 13
Manual Insertion Probe Instrument Regulator
Rev: B
Last updated: 9/8/2009
1.3 Specifications
The specifications listed in this Section are generalized for this equipment. Welker can modify the
equipment according to your company’s needs. However, please note that the specifications may vary
depending on the customization of your product.
Table 1
Specifications
Products
Natural gas or other gases or liquids compatible with the
materials of construction
Materials of Construction
316 Stainless Steel, Viton
®
, PTFE (others available)
Insertion Length
18" (457mm) Standard {others available in 1" (25.4mm)
increments}
Viscosity Range
0.009cp to 2,000cp @68°
F (20° C
Sample Outlet Connection
1
/
4
" NPT
Pipeline Connection
3
/
4
" or 1" NPT
Products
Natural gas or other gases or liquids compatible with the
materials of construction
Maximum Allowable Operating
Pressure*
2,160 PSIG @ -20°
F to 100°
F
(148 bar @ -29° C to 37° C)
Insertion Pressure*
Manual insertion and retraction up to 500 PSIG ONLY.
Operating pressure can then be increased to 2,160 PSIG MAX.
Output Range*
0-100 psi @ -20° F to 100 ° F
(0-6 bar @ -29° C to 37° C)
* Maximum allowable pressures and output ranges may be lower depending on specifications of the pipeline connection device.
