Well Tempered Lab LTD - Head-Shell Alignment Guide

20mm
Head-shell Alignment Guide for Well Tempered Lab Turntables
1. Cardboard 2. Centre of Tonearm tube 3. 19° Head-shell angle
150mm
Note: The Head-shell is factory fixed in position. Well Tempered Lab unequivocally reiterate that it should not be moved. Heavy handed mounting of the cartridge may result in moving the head shell. In which case place the above guide with centre line parallel to tone arm tube and align head shell to 19° angle. It will be necessary to gently but firmly retighten the small screw fixing the head-shell to the tonearm. Do not over-tighten this screw.
1
2
3
19°
