2-DVB-C/DTMB/ISDB-T signal
5-8VSB signal
6-FTA DVB-T/T2 signal
3-FTA or scrambled DVB-T/T2 signal
1-FTA or scrambled DVB-S/S2 signal
Picture A: Receiver
RF input
4-FTA DVB-S/S2/S2X signal
HDMI input
YPbPr input
CVBS input
SDI input
Pic A: Receiver module
Pic B: Encoder module
1 2 3
4 5 6
1 2 3
4 5 6
2-HDMI encoder with CC
5&6-CVBS encoder
3-HDMI encoder with YPbPr/CC
1-MPEG-2/H.264/HEVC HDMI encoder
Picture B: Encoder
4-SDI/CVBS encoder with CC
CMP200
To Next Page
