OWNERS MANUAL FOR WEISS JASON CD TRANSPORT
Page: 16 Date: 10/04 /dw
Frontpanel elements:
• Five switches for skip backward, skip forward, stop, play/pause and lid open/close.
• A high resolution graphical display.
• A power switch.
Backpanel elements from left to right:
• USB connector for software download (for future software upgrades).
• RCA and Toslink connector for fixed sampling rate 44.1kHz output.
• RCA, ST optical, BNC, XLR connectors for single wire 44.1 / 88.2 / 176.4 kHz output.
• 2 XLR connectors for dual wire 44.1 / 88.2 / 176.4 kHz output.
• Mains connector with fuses and voltage selector.
