OWNERS MANUAL FOR WEISS JASON CD TRANSPORT
Page: 21 Date: 10/04 /dw
Technical Data
Digital Outputs:
Output Connector type Format Available sampling rate(s) Available wordlengths
1 (2) XLR AES/EBU dual wire 88.2 / 176.4 *) 16 / 20 / 24 bits
2 XLR AES/EBU single wire 44.1 / 88.2 / 176.4 16 / 20 / 24 bits
3 BNC AES/EBU single wire 44.1 / 88.2 / 176.4 16 / 20 / 24 bits
4 RCA AES/EBU single wire 44.1 / 88.2 / 176.4 16 / 20 / 24 bits
5 ST optical AES/EBU single wire 44.1 / 88.2 / 176.4 16 / 20 / 24 bits
6 RCA S/PDIF single wire 44.1 **) 16 bits
7 Toslink S/PDIF single wire 44.1 **) 16 bits
*) This output is muted at the 44.1 sampling rate
**) This is fixed at 44.1, independent of the sampling rate setting
DSP algorithms:
Upsampling, volume control, phase inversion, POW-R algorithm # 3 wordlength reduction (dithering).
Power:
Mains Voltage: 100...120 / 200...240 Volt
Fuse rating: 500 mA slow blow
Power consumption: 50VA max.
Power consumption in standby: 2VA max.
