Wellsaw 58BD - Page 11

11
5
REF NO. PART NUMBER DESCRIPTION
100025-2 Lock Washer
3 A-12 Slide Block
4 100004-13 Cap Screw - 5/16 - 18 x 5/8 - Hex Head
Always give model number, serial number and part number when ordering repair parts.
WHEEL AND FRAME DETAILS
PARTS LIST
2 A-46 Wheel Slide Block Guide
1 102874 Frame
6 A-10 Wheel Adjusting Block
7 100004-18 Cap Screw - 5/16 - 18 x 1 - Hex Head
8 100029-3 Flat Washer
9 A-9 Wing Screw Block
10 102896 Wing Screw
11 A-17B Band Wheel - Idle End
12 100403-2 Ball Bearing
13 M-172 Spacer
14 M-429 Wheel Axle
15 100019-6 Hex Jam Nut
16 100065-7 Hex Nut
17 A-17A Band Wheel - Drive End
18 A-86 Ring Gear
19 100004-53 Cap Screw - 1/4 - 20 x 1 - Hex Head
20 100025-1 Lock Washer
21 102900 Wheel Plate
22 100004-15 Cap Screw - 5/16 - 18 x 3/4 - Hex Head
23 100034-3 Set Screw - 5/16 - 18 x 3/8
24 102903 Motor Support
25 100020-5 Nut - Self Locking
26 100042-10 Thumb Screw
27 100024-1 Wing Nut
28 1/3 H.P. Motor - Give Complete Electrical Specs.
29 101238 Pulley - Motor
30 100004-11 Cap Screw - 5/16 - 18 x 1/2 - Hex Head
31 102876 Wheel Guard
32
33
34
35
100000-17
100063
100218-1
100000-52
Machine Screw - #10 - 32 x 1/4 - Round Head
Thumb Screw
Clamp
Machine Screw - 1/4 - 20 x 1/4 - Round Head
36
37
38
39
102877
102905
102906
105811
Blade Guard
Stud
Belt Guard
Angle Wheel Guard
Wheel Guard - Drive End
41 102879 Wheel Guard - Short
40 105810
42
43
44
45
100004-26
100025-3
100004-67
100029-4
Cap Screw - 3/8 - 16 x 7/8 - Hex Head
Lock Washer
Cap Screw - 3/18 - 16 x 3 - Hex Head
Flat Washer
46 100017-3 Hex Nut
Wheel Ass'y Comp. - Idler - Incl. Items 11 thru 15102929
102930 Wheel Ass'y Comp. - Drive - Incl. Items 12 thru 15 & 17 thru 20
