Wellsaw 58BD - Page 13

13
5
REF NO. PART NUMBER DESCRIPTION
100405-1 Ball Bearing
3 100068-1 Snap Ring
4 100072-1 Expansion Plug
Always give model number, serial number and part number when ordering repair parts.
BLADE GUIDES AND GEAR BOX DETAILS
PARTS LIST
2 101291 Gear Case Cover
1 M-13 Gear Case
6 101343 Pulley Shaft
7 100056-10 Key
8 100414-3 Ball Bearing
9 100068-2 Snap Ring
10 100034-3 Set Screw
11 101292 Pulley
12 100066-2 "V" Belt
13 101286 Driven Gear
14 100404-1 Ball Bearing
15 101644 Drive Shaft
16 100004-16 Cap Screw - 5/16 - 18 x 7/8 - Hex Head
17 100025-2 Lock Washer
18 100000-29 Machine Screw - 1/4 - 20 x 1-1/2 - Round Head
19 101645 Drive Pinion
20 100053-5 Roll Pin
21 JK-57 Slide Block
22 100008-3 Cap Screw - 1/4 - 20 x 3/4 - Socket Head
23 105832 Guide Bracket - Idle End
24 102898 Wing Screw
25 102963 Movable Blade Guard
26 102961 Pivot Rod
27 100034-23 Set Screw
28 101297 Roller Support
29 100029-2 Flat Washer
30 100025-1 Lock Washer
31 100004-7 Cap Screw - 1/4 - 20 x 3/4 - Hex Head
32
33
34
35
100406-1
100030-4
101299
101298
Ball Bearing
Flat Washer
Eccentric Roller Axle
Roller Axle
36
37
38
39
101300
105830
105842
105844
Eccentric Axle Nut
Guide Bracket - Drive End
Blade Brush Angle - Long
Blade Brush Angle - Short
Blade Brush
41 100073-3 Weld Bolt
40 M-426
42
43
44
45
100017-1
100000-57
100027-3
100015-8
Hex Nut
Machine Screw - #10 - 32 x 1-1/8 - Round Head
Lock Washer
Hex Nut
Roller Support Ass'y - Drive or Idle - Incl. Items 28 & 32 thru 36
Blade Brush Ass'y - Inside - Incl. Items 38, 40, 41, & 42
46 102949 Stationary Blade Guard
Gear Box Ass'y Comp. - Incl. Items 1 thru 9 and 13 thru 20102901
105843 Blade Brush Ass'y - Outside - Incl. Items 39 thru 42
101643
101322
105841
Drive Shaft & Pinion - Incl. Items 15, 19 and 20
