9
55 102924 Table Support
53 100019-5 Hex Jam Nut
54 102923 Table Plate
52 102887 Ratchet Dog
51 100053-5 Roll Pin
56 102955 Stop Latch
57 100030-4 Flat Washer
58 100050-3 Cotter Pin
102922 Table Ass'y Opt. Equip. Incl. Items 23, 26, 28, 54 & 55
101709 Stock Stop Ass'y Opt. Equip. Incl. Items 28 thru 34
102931 Wheel & Handle Kit Opt. Equip. Incl. Items 26, 41, 42, 44 thru 51
56, 57, 58 and items 47 and 48 on Page 2
48
49
50
105818
102886
100034-1
Handle Rod
Collar
Set Screw - 1/4 - 20 x 3/16
46 100004-13 Cap Screw - 5/16 - 18 x 5/8 - Hex Head
47 Handle Grip105826
Mounting Block
Leg - Idle End
Wheel
Nut - Self Locking - 5/8 - 11
102937
102856
102938
100020-5
42
43
44
45
Thumb Screw
41 102932 Wheel Axle
40 100063
Leg - Drive End
Lock Washer - 1/2
Gasket
Split Leg - Idle End
102855
100025-5
105806
105802
36
37
38
39
Stop Arm
Stop Arm Housing
Set Screw - 5/16 - 18 x 7/8
Split Leg - Drive End
A-13
A-36
100034-6
105803
32
33
34
35
30 100033-23 Set Screw - 3/8 - 16 x 2-1/2
31 100017-3 Hex Nut - 3/8 - 16
28 100034-3 Set Screw - 5/16 - 18 x 3/8
29 A-62 Stop Bar
26 100025-2 Lock Washer - 5/16
27 100004-15 Cap Screw - 5/16 - 18 x 3/4 - Hex Head
24 105845 Bed
25 101750 Tip-Off Block
22 100017-5 Hex Nut - 1/2 - 13
23 100004-13 Cap Screw - 5/16 - 18 x 5/8 - Hex Head
20 105839 Vise Slide Block
21 105840 Vise Slide Block Guide
18 M-65 Locating Pin
19 A-151 Clamp Nut
16 A-31 Stationary Vise Jaw
17 100004-38 Cap Screw - 1/2 - 13 x 2 - Hex Head
14 100004-37 Cap Screw - 1/2 - 13 x 1-1/2 - Hex Head
15 100029-6 Flat Washer - 1/2
12 105847 Movable Vise Jaw
13 100004-39 Cap Screw - 1/2 - 13 x 2-1/2 - Hex Head
10 102891 Vise Ratchet Dog (after SN23617 use 120232)
11 100053-2 Roll Pin - 3/8 x 2-1/2
8 100053-5 Roll Pin
9 100004-20 Cap Screw - 5/16 - 18 x 1-1/4 - Hex Head
6 102890 Vise Ratchet (after SN23617 use 102890)
7 102957 Clamp Block
102889 Vise Screw
Always give model number, serial number and part number when ordering repair parts.
BED AND LEG DETAILS
PARTS LIST
2 100019-8 Hex Jam Nut
1 A-16 Hand Wheel
5
REF NO. PART NUMBER DESCRIPTION
M-61 Vise Screw Nut
3 100402 Thrust Collar
4
