EXPLODED VIEW & PARTS LIST
14
No. Part No. Description Qty.
1 40415-001 Battery Housing 1
2 40415-002 Switch 1
3 40415-003 Switch Spring 2
4 40415-004 Trigger 1
5 40415-005 PCB Board 1
6 40415-006 PCB Guard 1
7 40415-007 Battery Spring 1
8 40415-008 Left Housing 1
9
40415-009
Handle Assembly 1
9.1 Countersunk Screws 4
9.2 Left Plate 1
9.3 Right Plate 1
9.4 Front Handle 1
9.5 Spring 1
9.6 Handle Support 1
9.7 Hand Guard 1
9.8 Screws 2
10 40415-010 Switch 1
11 40415-011 Insulator 2
12 40415-012 Screw 2
13 40415-013 Gear Box Assembly 1
13.1
40415-M
Motor Assembly 1
13.1.1 Stator / Rotor 1
13.1.2 Motor Gear 1
13.2 40415-014 Hex Nuts 2
13.3 40415-015 Gear Box 1
No. Part No. Description Qty.
13.4 40415-015 Screw 2
13.5
40415-016 626 Bearing 1
13.6
40415-017 Spindle Bushing 1
13.7
40415-018 Gear 1
13.8
40415-019 Output Shaft 1
13.9
40415-020 608Z Bearing 2
13.10
40415-021 Output Shaft Assembly 1
13.10.1 40415-022 Output Shaft 1
13.10.2 40415-023 Drive Gear 1
13.10.3 40415-024 Wobbler 2
13.10.4 40415-025 Blade Assembly 1
13.10.5 40415-026 Blade Spacer 1
13.10.6 40415-027 Base Plate 1
13.10.7 40415-028 Pin 2
13.11 40415-029 Bushing 1
13.12 40415-030 607 Bearing 1
13.13 40415-031 End Cover 1
13.14 40415-032 Screw 4
14 40415-033 Guide Bar Sheath 1
15 40415-034 Battery Latch 1
16 40415-035 Insulator 2
17 40415-036
Screw 2
18 40415-037
Right Housing 1
19 40415-038 Screws 15
20 40401
Battery 1
21 40400
Charger 1
