UNPACKING

Carefully remove the tool and any accessories from the box. Make sure that all items listed in the packing list are

included. If any part is damaged or missing, please contact our customer service at (800) 232-1195, M-F 8-5 CST.

PACKAGING LIST

The following items are included with the tool:

1. Top Plate

2. Hook

3. Water Pot Assembly

4. Column

5. Base

6. Set Screw M10x10

Extra Hardware

Bag

12-3/8

16-1/2

14-1/2

31-1/2

2-3/4

7. M4x8 Phillips Pan Head Screw

8. 5 mm Inner Hex Wrench

9. Hex Bolt M8x50

10. Flat Washer D8

11. Spring Washer D8

12. Hex Nut M8

COMPONENTS

9-7/8

3-7/8

7-1/2

Ø1/2
