No. Part Number Description Specication Qty.

1 56035-G-001 Eccentric Block 2

2 56035-G-002 Oil Seal 28 x 50 x 10 2

3 56035-G-003 Bearing Cover 2

4 56035-G-004 Bearing 6306 2

5 56035-G-005 Bearing Seat 1

6 56035-G-006 Key 6 x 6 x 20 3

7 56035-G-007 Main Shaft 1

8 56035-G-008 Inner Hexagon Bolt M6 x 16 6

9 56035-G-009 Spring Gasket Ø6 6

10 56035-G-010 Clip Ø24 2

11 56035-G-011 Pulley 84 x 35 1

12 56035-G-012 Conical Flat Washer 8 x 30 x 6 1

13 56035-G-013 Spring Washer Ø8 1

14 56035-G-014 Inner Hexagon Bolt M8 x 20 1

EXPLODED VIEW AND PARTS LIST (VIBRATOR ASSEMBLY)

NOTE: These parts are only available as a complete assembly (vibrator assembly, part 56035-023).

If you wish to purchase this assembly, please visit www.wenproducts.com
