Wen LM2173

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 LM2173-101 Bolt M6X12 7
2 LM2173-102 Cylinder Cover 1
3 LM2173-103 Cylinder Gasket 1
4 LM2173-104 Rocker Arm 2
5 LM2173-105 Push Plate 1
6 LM2173-106 Valve Spring Seat 2
7 LM2173-107 Valve Spring 2
8 LM2173-108 Return Intake Valve 2
9 LM2173-109 Intake Valve 1
10 LM2173-110 Exhaust Valve 1
11 LM2173-111 Spark Plug 1
12 LM2173-112 Enriched Air Line 1
13 LM2173-113 Bolt M6X25 1
14 LM2173-114 Circular Plate 1
15 LM2173-115 Governor Plate 1
16 LM2173-116 Push Rod 2
17 LM2173-117 Lifter Valve 2
18 LM2173-118 Camshaft Assembly 1
19 LM2173-119 Piston Scraper Ring Set 1
20 LM2173-120 Piston 1
21 LM2173-121 Piston Pin 1
22 LM2173-122 Piston Clip 2
23 LM2173-123
Connecting Rod Assem-
bly
1
24 LM2173-124 Cylinder 1
25 LM2173-125 Oil Seal 1
26 LM2173-126 Flange Nut M6 3
27 LM2173-127 Adjustable Rocker Arm 2
28 LM2173-128 Shroud 1
29 LM2173-129 Breather Valve Spring 1
30 LM2173-130 Breather Filter 1
31 LM2173-131 Muffler Assembly 1
32 LM2173-132 Stud Bolt 2
33 LM2173-133 Fuel Tank Cap 1
34 LM2173-134 Fuel Tank 1
35 LM2173-135 Fuel Tank Gasket 1
36 LM2173-136 Recoil Starter Housing 1
LAWN MOWER
NO. PART NO. DESCRIPTION QTY.
37 LM2173-137 Bolt M6X16 4
38 LM2173-138 Fuel Filter 1
39 LM2173-139 Wind Deflector 1
40 LM2173-140 Fuel Line 1
41 LM2173-141 Governor Arm Shaft 1
42 LM2173-142
Governor Arm Shaft
Washer
1
43 LM2173-143 Governor Arm Shaft Seal 1
44 LM2173-144 Lock Oin 1
45 LM2173-145 Governor Arm 1
46 LM2173-146 Recoil Starter Bolt Stud 1
47 LM2173-147 Disc Nut M6 2
48 LM2173-148 Governor Rod 1
49 LM2173-149 Throttle Return Spring 1
50 LM2173-150 Governor Spring 1
51 LM2173-151 Nut 2
52 LM2173-152 Upper Shroud Assemble 1
53 LM2173-153 Breather Tube 1
54 LM2173-154 Exhaust Gasket 1
55 LM2173-155 Crankshaft 1
56 LM2173-156 Nut 2
57 LM2173-157 Crankshaft Washer 1
58 LM2173-158 Governor Assembly 1
59 LM2173-159 Breather Chamber Gasket 1
60 LM2173-160 Breather Chamber Cap 1
61 LM2173-161 Dowel Pin 2
62 LM2173-162
Crankcase Cover Assem-
bly
1
63 LM2173-163 Oil Seal 1
64 LM2173-164 Bolt M6X18 6
65 LM2173-165 Bolt M6X45 2
66 LM2173-166 Engine Hood 1
67 LM2173-167 Recoil Starter Assembly 1
68 LM2173-168 Dipstick 1
69 LM2173-169 Nut M6 2
70 LM2173-170 Brake Assembly 1
71 LM2173-171 Ignition Coil Assembly 1
