Wen WA1300 User Manual

11
EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 WA1300-001 M10x88 Bolt 1
2 WA1300-002 Side Panel 2
3 WA1300-003 Grip Cover 2
4 WA1300-004 M10x93 bolt 1
5 WA1300-005 Worktop 1
6 WA1300-006 Right Side Braket with Hole 1
7 WA1300-007 Washer Ø10 2
8 WA1300-008 Spring washer Ø10 2
9 WA1300-009 Acorn Nut M10 2
10 WA1300-010 Short Shaft Spacer 4
11 WA1300-011 Elbow Support 1
12 WA1300-012 M8x12 Carriage Bolt 8
13 WA1300-013 Straight Support 1
14 WA1300-014 Spring 2
15 WA1300-015 Positioning Pin 2
16 WA1300-016 M6 Lock Nut 2
17 WA1300-017 Upper Leg 4
18 WA1300-018 Height Adjust Lever 4
19 WA1300-019 Lower Leg 4
20 WA1300-020 Workpiece Support Block 2
21 WA1300-021 M6x65 Flathead Screw 4
22 WA1300-022 Foot 4
23 WA1300-023 M5 Lock Nut 4
24 WA1300-024 Support Beam 2
25 WA1300-025 Spacer Sleeve 4
26 WA1300-026 M6x65 Bolt 2
27 WA1300-027 Circlip 2
28 WA1300-028 Bracket Cap 2
29 WA1300-029 Left Side Bracket 1
NOTE: Not all parts may be available for purchase.

Wen WA1300 Specifications

General

Brand	Wen
Model	WA1300
Category	Power Tool Accessories
Language	English
