UNPACKING & PARTS LIST
Carefully take out all the parts from the packaging. Check all components and compare against the diagram be-
low. Organize them for assembly. If any part is damaged or missing, please contact our customer service at (800)
232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com.
4
No. Part No. Description Qty.
1 WB2322-001 Table Top 1
2 WB2322-002 Side Support 2
3 WB2322-003 Wide Bracket 1
4 WB2322-004 Narrow Bracket 3
5 WB2322-005 Foot Bar 1
6 WB2322-006 Leg 2
7 WB2322-007 Angle Lock Knob 2
8 WB2322-008 Peg 4
No. Part No. Description Qty.
9 WB2322-009 Clamp 4
10 WB2322-010 Washer, M6 32
11 WB2322-011 Hex Nut, M6 16
12 WB2322-012 Lock Nut, M6 4
13 WB2322-013 Screw, M6*10 4
14 WB2322-014 Screw, M6*35 4
15 WB2322-015 Screw, M6*40 12
1
3 4 5 6
2
7
10
13
8
11
14
9
12
15
32
