COMPONENT LIST
1. Tool holder locking sleeve
2. Depth gauge lock screw
3. Depth gauge
4. Hammer or chisel action selector switch
5. Selector switch lock button
6. Grease box cover
7. On/Off switch
8. Hammer or drilling action selector switch
9. Auxiliary handle
TECHNICAL DATA
Type WS3202K WS3202K.1 (32 - designation of machinery, representative of rotary hammer)
WS3202K WS3202K.1
Rated voltage 230V~50Hz
Rated power 1500W
No load speed 850 /min
Impact rate
4200 /min
Impact energy
5.5J
Max. Drilling capacity
Steel
13mm
Concrete
32mm
Wood
40mm
Protection class
/II
Machine weight 5.73kg
NOISE INFORMATION
A weighted sound pressure L
pA
= 92.7 dB(A)
A weighted sound power L
wA
= 103.7 dB(A)
K
pA
&K
wA
3.0 dB(A)
Wear ear protection.
VIBRATION INFORMATION
Vibration total values (triax vector sum) determined according to EN 62841:
Hammer drilling into concrete
Vibration emission value a
h,HD
= 17.360 m/s²
Uncertainty K = 1.5 m/s²
Chiseling
Vibration emission value a
h,CH
= 13.334 m/s²
Uncertainty K = 1.5 m/s²
The declared vibration total value and the declared noise emission value have been measured in accordance with a standard test method and
may be used for comparing one tool with another.
The declared vibration total value and the declared noise emission value may also be used in a preliminary assessment of exposure.
WARNING: The vibration and noise emissions during actual use of the power tool can differ from the declared value depending on the
ways in which the tool is used especially what kind of workpiece is processed dependant on the following examples and other
variations on how the tool is used:
