12. Attach the Backrest (45) to the Seat Upright (64)
with four M6 x 16mm Hex Head Screws (46).
8
45
46
64
12
63
46
25
55
26
55
25
12
63
12
44
10. Attach the Seat (44) to the Seat Bracket (63) with
four M6 x 16mm Hex Head Screws (46).
11. Attach the Seat Handles (25) to the Seat Bracket
(63) with two M8 x 100mm Hex Head Bolts (12),
two M8 Washers (26), and two M8 Nylon Locknuts
(55).
11
9. Attach the Seat Bracket (63) to the Seat Upright
(64) with four M8 x 65mm Carriage Bolts (52) and
four M8 Nylon Locknuts (55).
63
64
55
52
9
10
26
