Wespro Power Tools PS400 - Nosepiece Assembly Part Selection; Draw Bolt Size to Nosepiece Mapping

Draw Bolt
Nominal
Size
Nosepiece
Assembly
Nosepiece
(6)
Thrust
Washer
(5)
Thrust
Roller
Bearing
(4)
Rear Thrust
Plate
(3)
Draw Bolt
(2)
Draw Bolt
Driver
(1)
#4
NPA-#4
NP-#4(3mm)
TW-01
TB-01
TP-#4(3mm)
W04040
DBD-#4
205376
205363
143763
143762
205365
205373
205371
#6
NPA-#6
NP-#6
TW-01
TB-01
TP-#6
W06032
DBD-#6
140401
148989
143763
143762
135520
120830
135524
#8
NPA-#8
NP-#8(4mm)
TW-01
TB-01
TP-#8(4mm)
W08032
DBD-#8
136348
148993
143763
143762
135521
125209
148979
#10-24
NPA-#10
NP-#10(5mm)
TW-01
TB-01
TP-#10(5mm)
W10024
DBD-#10(5mm)
136350
148996
143763
143762
135522
125210
136355
#10-32
NPA-#10
NP-#10(5mm)
TW-01
TB-01
TP-#10(5mm)
W10032
DBD-#10(5mm)
254121
148996
143763
143762
135522
120828
136355
1/4"-20
NPA-1/4
NP-1/4
TW-01
TB-01
TP-1/4(6mm)
W14020
DBD-1/4
136351
143764
143763
143762
143761
118721
140876
1/4"-28
NPA-1/4
NP-1/4
TW-01
TB-01
TP-1/4(6mm)
945-917-1
DBD-1/4
283363
143764
143763
143762
143761
59705
140876
5/16"
NPA-5/16
NP-5/16(8mm)
TW-01
TB-01
TW-01
W51618
DBD-5/16
136352
143768
143763
143762
143763
125211
136356
3/8"
NPA-3/8
NP-3/8
TW-02
TB-02
TW-02
DB-3/8-16
DBD-3/8(10mm)
136353
143767
135555
134954
135555
135523
149007
3mm
NPA-3mm
NP-#4(3mm)
TW-01
TB-01
TP-#4(3mm)
DB-3mm
DBD-3mm
193364
205363
143763
143762
205365
205369
205370
4mm
NPA-4mm
NP-#8(4mm)
TW-01
TB-01
TP-#8(4mm)
M04007
DBD-4mm
136358
148993
143763
143762
135521
125216
132866
5mm
NPA-5mm
NP-#10(5mm)
TW-01
TB-01
TP-#10(5mm)
M05008
DBD-#10(5mm)
136360
148996
143763
143762
135522
109913
136355
6mm
NPA-6mm
NP-6mm
TW-01
TB-01
TP-1/4(6mm)
M06010
DBD-6mm
140868
198361
143763
143762
143761
124497
143686
8mm
NPA-8mm
NP-5/16(8mm)
TW-01
TB-01
TW-01
M08125
DBD-8mm
136359
143768
143763
143762
143763
109912
133514
10mm
NPA-10mm
NP-10mm
TW-02
TB-02
TW-02
DB-10mm
DBD-3/8(10mm)
132769
173522
135555
134954
135555
135557
149007
