This Service Guide is designed as a reference tool to help pinpoint service needs of the Wessel-Werk TK
286 Turbo Brush.
o #10 Torx Screw Driver
o Medium Flat Head Screw Driver
Common Spare Parts
o Brush Assembly Complete
o Geared Belt
o Front Wheel with axel
o Rear Wheel with Axel
o Clean-out door
o Pivot Arms
Warning!
o Do not over tighten screws as screw holes can become stripped.
o When refastening screws always use the original thread pitch of the screw hole. Failure to use
the original screw orientation will likely drill-out material and strip hole.
o Easiest way to find the original thread orientation is by counter rotating the screw before turning
the screw into the hole.
o Manually replace screws! Use of a power screw driver is not recommended for reassembly.
Only Use original replacement parts!
For best results- Only Use original replacement parts!
To avoid warranty invalidation only use original replacement parts!
