8
ETL-ES-Chambers-WH18
NORMAL DOWNROD OPTION
OPCIÓN CON VARILLA VERTICAL NORMAL
Quite el pasador tipo prensa (1) desde el pasador transversal (2) de la varilla vertical (3).
6
Remove clamp pin (1) and cross pin (2) from downrod (3).
1
2
3
