DC Inverter U-match Series Cassette Type Unit
10
2 3 3 2
Unit
：
mm
Dimensions
A B C D E F G
950 890 840 680 780 200 135
950 890 840 680 780 240 135
950 890 840 680 780 290 135
NOTES!
(1) Drilling of ceiling opening and installation of air conditioner must be performed
(2) Please refer to the installation cardboard for the dimension of drilling hole of
lifting screw of cassette unit.
2
3
3
2
