Westpoint 12K - Standard Accessories

DC Inverter U-match Series Cassette Type Unit
49
3.2 Standard Accessories
Indoor Unit Accessories
No.
Name
Appearance
Q'ty
Usage
1 Drain Hose 1
To connect with the hard
PVC drain pipe
2 Bolt with Washer 4
To fix the installation
paperboard on the unit
3
Installation
Paperboard
1 Used for ceiling drilling
4
Gasket Mounting
Board
4
Used to prevent gasket
from falling off
5
Wireless Controller
+Battery
1+2 To control the indoor unit
6 Insulation 1 To insulate the gas pipe
7 Insulation 1 To insulate the liquid pipe
8
Ordinary Nut+
Tamperproof box
+
1
To prevent the removal of
the gas pipe connecting
nut
9
Ordinary Nut+
Tamperproof box
+
1
To prevent the removal of
the liquid pipe connecting
nut
10
Heat-Shringkable
Bushing
1
Connect the front panel to
the main body
11 Flannelette 1
To prevent the
communication wire from
reaching out the electric
raceway
(only GUD35T1/A-S,
GUD50T1/A1-S)
12 Bolt Assembly 4
Connect the panel and
body(only GUD35T1/A-S,
GUD50T1/A1-S)
13
Buckle magnetic
ring+ Cable tie
+
1+1
For engineering
installation.
(only GUD35T1/A-S,
GUD50T1/A1-S,
GUD140T1/A-S,
GUD160T1/A-S)
