DC Inverter U-match Series Cassette Type Unit
45
2) Outdoor side
Remove the big handle/front panel of the outdoor unit and insert one
end of the communication cord and the power cord to the terminal
board.
Wire routing of outdoor unit
：
12K, 18K, 24K, 30K
36K, 42K, 48K
